You need to use an Administrator account during the installation process and every time you run SolidCAM.Setting up SolidCAM 2011 for the first time (64 bit) The G-code is also saved in the CAM-part folder with an. Notepad will open with the G-code output.To get the G-code output, right click on Operations in the SolidCAM Manager and select GCode All > Generate.The feed and spin data are reasonable starting points for machining in blue machinable wax. If you are using the Haas, the tool table should already be loaded.From this point, you can create machining operations with SolidCAM.*Optional*: Under iMachining Data > Machine Database, select the correct CNC machine in the drop-down menu (Levil_WL400 or HAAS_VF-0E).Define the coordinate system, stock model, and target model as appropriate.Configure the CAM-part in the FeatureManager area on the left of the screen.Make sure this folder does not already exist. The CAM-part folder will be created at the location specified by "Directory" with the name specified by "Name". Open SolidCAM with the menu bar by going to SolidCAM > New > Milling, or open it by going to the SolidCAM Part tab and clicking New > Milling.Make sure there are no other files open at the same time as the file you are machining.Now, open your SolidWorks part that you want to machine.Press OK to close the SolidCAM Settings window.A pop-up box appears saying "All the current SolidCAM Settings will be overwritten.Haas VF-0E: SolidCAM_Settings_Haas.screg.Levil WL400: SolidCAM_Settings_Levil.screg.Choose the settings file (.screg) corresponding to the CNC machine you are using and click Open.In the dialog box which opens, navigate to "Program Files/SolidCAM2011/User" if that folder is not already open by default.In the lower left corner of the SolidCAM Settings window, click on the small icon showing a folder with an arrow pointing upwards (the tooltip reads "Load settings from a file".
